Intel Core i7 10510U Industrial PC Dual Ethernet 6COM Industrial PC Built In GPIO
Intel Core Industrial PC Description:
This industrial mini computer is equipped with a high-performance processor, runs very fast, and can respond quickly to various complex instructions. It has good stability and compatibility, can support large-scale data computing and collaborative operation of multiple software, and provide solid computing support for your industrial production.
The body of this desktop mini pc is made of aluminum alloy chassis, which is resistant to pressure and impact. It can run steadily regardless of accidental collision or vibration. And it also has excellent high and low temperature resistance. It can maintain a stable working state in high temperature and hot or low temperature and cold environment.
The fully enclosed design adds protection to it, with dustproof, moisture-proof, anti-interference and anti-corrosion characteristics, which can easily cope with harsh environments such as dusty, humid, and strong electromagnetic interference in industrial production.
Intel Core Industrial PC Specification:
| CPU | Intel Core i7-10510U 4 Cores 8 Threads Processor, 4.90 GHz Max Turbo Frequency, 8 MB Intel® Smart Cache, 15W TDP |
| Hard Disk | 1x SATA NVME/NGFF 2280 SSD 1x M.2 SSD Supports NGFF 2242 or 4G/5G Module Expansion |
| Memory | 1x DDR4 SODIMM RAM, Max Up To 32GB |
| Extension | 1x M.2 Slot, Supports NGFF 2242 or 4G/5G Module Expansion; 1x M.2 Slot, Supports WiFi 6/Bluetooth/4G Module Expansion;
1x SIM Slot |
| Ethernet | 2*Ethernet, Intel I226-V network card, Support wake-up on LAN, PXE Boot |
| Display | 1*HDMI1.4, 1*DP, 1*LVDS/EDP, Support Three-screen Synchronous and Asynchronous Display |
| Built-in | Built-in LVDS and 8-way GPIO |
| Operating System | Windows 10, Windows 11, Linux, etc. |
| I/O Interface | 4*USB3.0, 4* USB2.0; Built-in 2*USB2.0 pins; 6*COM RS232 (COM1: RS232/422/485, COM2: RS232/485, COM3: TTL/RS232); 1 x AUD: On-board ALC269 Audio Decoding Controller; 1 x Power Button; 1 x DC Power Socket, Supporting 12V |
| Power | DC 12V 5A |
| Cooling Method | Low-power and Low-noise Fan Design |
| Material | Aluminum Alloy Chassis |
| Installation | Desktop and Wall-mounted Models |
| Dimension | 235mm*137mm*52mm |
| Suitable Temperature | Storage temperature: -25℃ to +75℃; Working temperature: -10℃ to +60℃; Storage humidity: 5% to 95% (Relative Humidity, No Condensation) |
Intel Core Industrial PC Details:
It is equipped with a powerful Intel i7-10510U processor, and its ultra-high performance can be used in the industrial field. The 4-core 8-thread architecture, with 8MB cache, and the maximum turbo frequency can reach 4.9Ghz, runs very fast and has high efficiency. It can support complex data processing tasks or running multiple programs at the same time.
As a industrial mini pc which supports three-screen display function, which can realize synchronous or asynchronous output. This feature allows you to monitor all data and equipment operation status in the industrial production process in an all-round way. The multi-dimensional information display makes your management and decision-making more accurate and efficient.
Most importantly, it can support 7×24 hours of uninterrupted long-term operation. In the rhythm of industrial production that races against time, it protects your production line with lasting endurance, reduces downtime and improves production efficiency.
For self - service cash registers, it provides a reliable and efficient computing core. With its stable performance, customers can enjoy a seamless self-checkout experience, reducing waiting times and improving overall shopping satisfaction.
In factory production workshops, industrial mini pcs play a crucial role. They can be integrated into the production line control systems, enabling real-time monitoring and precise control of the production process. This ensures high - quality output and increased productivity.
